CP34/44/54 Echo menu Chapter 4-1
4. Echo menu
2
ECHO
1
Depth & temperature diagram
2
Custom screen
4.1 Depth & temperature diagram
MENU
Call up the menu bar, and...
2,1
activate Depth & temperature diagram
Present water
temperature
and depth.
Depth over
time or dis-
tance.
Temperature
over time or
distance.
ADJ
Call Setup for Depth - see example next page.
