Simrad HS 75 - Dimensions; Physical Dimensions and Mounting Details

12
DIMENSIONS
94.0 mm
(3.70 “)
63.5 mm
(2.50 “)
348.2 mm
(13.71 “)
9.5 mm
(0.37 “)
158.4 mm
(6.23 “)
74.45 mm
(2.93 “)
Qty. 4 - M8x1.25 - 12.7 (0.50 “)
