17
TECHNICAL SPECIFICATIONS
Sensor and positioning accuracy Purpose
Receiver type Vector sFreq GNSS Compass
Signals received GPS, GLONASS, BeiDou, Galileo, QZSS1
Channels 422
GPS sensitivity -142 dBm
SBAS tracking 2-channel, parallel tracking (WAAS, EGNOS, MSAS)
Update rate (position and heading) 10 Hz standard
Positioning accuracy 1.2m RMS, (no SA)
0.3m RMS, (SBAS)
Heading accuracy 0.75° RMS
Heave accuracy (GNSS) 30 cm
Pitch/Roll accuracy 1.5° RMS
Rate of turn 90°/s maximum
Cold start 60 s typical (no almanac or RTC)
Warm start 20 s typical (almanac and RTC)
Hot start 1 s typical (almanac, RTC, and position)
Heading x 10 s typical (valid position)
Maximum speed 1,850 kph (999 kts)
Maximum altitude 18,288 m (60,000 ft)
Compass safe distance 50 cm
Power Purpose
Input voltage 6 - 36 V DC
Power consumption 3.2 W (multi-GNSS, typical continuous draw at 12 V)
Power isolation Isolated to enclosure
Reverse polarity protection Yes
