Simrad HS 75 - Mechanical and Environmental Ratings

18
Communication Purpose
Connector NMEA 2000
®
Micro C
Mechanical Purpose
Weight (no mount) 0.75 kg
Dimensions (no mount) L 34.8 cm x W 15.8 cm x H 6.5 cm
L 13.7” x W 6.2” x H 2.6”
Aiding devices
Six-axis rate sensor (gyro) Provides smooth heading, fast heading reacquisition
and reliable 1˚ per minute heading for periods up to
3 minutes when loss of GNSS has occurred.
Tilt sensor Provides pitch and roll data and assist in fast start-up
and reacquisition of heading solution.
Environmental Purpose
Operating temperature -40°C to + 70°C (-22°F to + 158°F)
Storage temperature -40°C to + 85°C (-40°F to + 185°F)
Humidity 95% non-condensing
Enclosure ISO 60529:2013 for IPx6/IPx7/IPx9
Vibration IEC 60945:2002 Section 8.7 Vibration
EMC IEC60945:2002
EN 301 489-5 V2.1.1
EN 303 413 V1.1.1
