Simrad NSS7 EVO3 COMBO Quick Start Guide

4
|
NSS evo3 | QuickStart Guide - EN
Instruments bar
Tap the Instrument bar button in the System Control dialog to turn
the bar on/off.
To edit the content of the Instrument bar:
1. Tap the Instrument bar to make it active
2. Select the edit option from the menu
3. Tap the item you want to change
4. Select the information you want to display in the Instrument bar
5. Save the changes by selecting the save option in the menu.
Charts
A
• Zoom the chart by using spread or pinch
gestures, by using the zoom buttons (A), or by
turning the
Rotary knob.
• Move the view in any direction by panning the
chart.
• Display information about a chart item by tapping
the item.
Waypoints
¼ Note: With cursor inactive, the waypoint will be placed at vessel’s position. With
cursor active, the waypoint will be placed at selected cursor position.
To create a waypoint:
• Press the
Mark key to instantly add a waypoint.
• Press the
Rotary knob, or use the new waypoint option in the menu to
open a New waypoint dialog.
