Simrad R2009 Quick Reference Card

PI lines menu
Stabilization [ = ]
Bearings [ = ]
Enable all PI
Disable all PI
Parallel index 1 [ √ ]
0.0NM 0.0°
Adjust…
Parallel index 2 [ √ ]
0.0NM 0.0°
Adjust…
Parallel index 3 [ √ ]
0.0NM 0.0°
Adjust…
Parallel index 4 [ √ ]
0.0NM 0.0°
Adjust…
Main menu
View 
Maps [ √ ]
Apply default settings
User settings 
TT/AIS 
Speed source 
PPI symbols 
PI1 reset
PI2 reset
PI3 reset
PI4 reset
PM [ √ ]
Advanced 
Settings...
Main menu
Access the main menu by pressing the Menu softkey. Use the arrow keys or rotary knob to move around in the menus and access
the highlighted function by pressing the ENT key.
R3016 12U/6X
View menu
Trails & PAST POSN 
Orientation ≡
Motion mode [ = ]
True motion reset
Offset 
Vectors 
Cursor bearings [ = ]
Brilliance 
User settings menu
Save settings ≡
Load settings ≡
Trails & PAST POSN menu
Presentation [ = ]
Trails [ √ ]
Clear trails
Length ≡
Past positions [ √ ]
Time ≡
Interval ≡
Oset menu
Look ahead [ √ ]
Set offset...
Vectors menu
Vectors [ √ ]
Presentation [ = ]
Time ≡
Brilliance menu
Video radar [----]
Own ship [----]
NAV symbols [----]
Menu [----]
TRKG symbols [----]
PPI symbols menu
PI lines 
Maps...
Range rings [ = ]
Heading line off
Overlay graphic off
TT/AIS menu
Cancel all
Cancel selected target
CPA/TCPA limit...
AIS 
Target association 
Training [ √ ]
Speed source menu
Stabilization [ = ]
Sources ≡
Manual speed [123]
Drift/Set [ √ ]
Drift [123]
Set [123]
AIS menu
Class filter ≡
Range filter [ √ ]
Range [123]
Speed filter [ √ ]
Speed [123]
AUTO-Activation [ √ ]
Lost warning [ √ ]
Physical AtoN [ √ ]
Virtual AtoN [ √ ]
Target association menu
Target ASSOC ≡
Range [123]
Delta speed [123]
Delta course [123]
Advanced menu
IR ≡
Noise rejection ≡
Target boost ≡
Target expansion ≡
Fast scan mode [ √ ]
