Operating Manual TRACSCAN 2.0
V2.0, 2022-05 33 / 36
9. Technical Data
TRACSCAN 2.0
Dimensions
28.8cm (length) x 17.8cm (width) x
11.5cm (height); height is
15.4cm with handle
Weight 7720g
Max Speed 200mm/s
Test Foot Downforce 2354g (24N)
Storage Conditions -20°C to +50°C; 5% to 85% RH without condensation
Operation Conditions 0°C to +40°C; 10% to 80% RH without condensation
Interfaces
USB B for charging and data communication; Bluetooth LE 5.1 for
data communication
Archive
Size
Up to 2048 measurements; oldest record is overwritten if maxi-
mum size has been reached.
Printer
Type Thermal printer
Paper Length 16m (approximately), width 112mm
Battery
Type 10 cells NiMH (Nickel Metal Hydride), rechargeable
Voltage 12 V
Capacity 2.0 Ah
Replacement
The battery cannot be accessed by the user. It can be replaced by
the manufacturer, if required.
Table 16: Technical Data TRACSCAN 2.0
Charger
Input 110 / 230 V, 50 / 60 Hz
Output USB A, 5 V, 1.5 A or greater
Table 17: Battery Charger
