GD1 Page 60 of 76 850-816926-EN R06
TEMPERATURE RANGE
Operating -55°C to + 65°C (-67°F to +149°F)
ATEX Flameproof -55°C to + 75°C (-67°F to +167°F)
IECEx Flameproof -55°C to + 75°C (-67°F to +167°F)
ENVIRONMENTAL
Ingress protection IP66 / IP67 IEC 60529
Humidity (operation) 0 – 100% RH
Humidity (storage) 0 – 95% RH
MECHANICAL
TX and RX Housing:
- Material Stainless steel (ASTM 316)
- Weight 6 Kg (12 lbs) (each)
- Dimensions Ref outline drawing
Junction Box:
- Material GRP
- Weight 2.0 Kg (4.4 lbs) (each)
- Dimensions Ref outline drawing
Total assembly weight 12 kg (26 lbs) (Tx or Rx + JB + bracket + plate)
OUTLINE DIMENSIONS
