Page 34/38
Original issue
May, 2014
Service Manual
7285Q
Model
17. Electronic component area -- continued --
Harnesses are connected to red
framed position of CPU board
LCD Unit p.no. 84082
CN4
CN5
CN6
CN7
Reverse side of CPU /Switch board
CN9
CN10
CN8
not used
