© Oct. 2022 1-2 GTZZ18J Operation Manual
PERFORMANCE PARAMETERS
Table 1-1 GTZZ18J specifications (continued)
MEASURE
AB18J (Metric) AB600J (Imperial)
Max operating noise level
82 dB
POWER PARAMETERS
Engine (rated power, rated rpm) Cummins QSF2.8t3NA60 (43 kW, 2500 rpm)
Hydraulic tank capacity
110 L
24.2 gal (UK)/29 gal (US)
Fuel tank capacity
110 L
24.2 gal (UK)/29 gal (US)
Hydraulic system pressure 28 MPa 3046 psi
Battery (number×voltage, capacity) 2×12V
System voltage
12 VDC
Control voltage 12 VDC
GROUND BEARING DATA
Max tire load
6280 kg
13845 lb
Tire contact pressure
830 kPa
120 psi
ENVIRONMENT REQUIREMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280 ft
Allowable ambient temperature
(lead-acid battery)
-10℃～40℃ 14℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gas, inflammables and explosives.
WEIGHT
Gross weight (unladen) 10700 kg (4WD) 23589 lb (4WD)
Note:
a) The platform height plus the operator height (taken as 2m [6ft 7in]) is the working height.
b) The ground bearing data is approximate, without factoring different configurations, and should only be used in adequately
safe conditions.
c) In different areas, hydraulic oil, engine oil, coolant, fuel and lubricant should be added in accordance with the environmental
temperature.
d) In cold climates, auxiliary devices are needed to start the machine.
e) The loads of persons, accessories, tools and materials are factored into the rated platform capacity.
f) The total vibration value of the platform does not exceed 2.5m/s², and the maximum root-mean-square value of the weighted
acceleration of the entire machine does not exceed 0.5m/s².
