GTZZ18J Operation Manual 1-1 © Oct. 2022
1 PERFORMANCE PARAMETERS
Table 1-1 GTZZ18J specifications
MEASURE
AB18J (Metric) AB600J (Imperial)
DIMENSION PARAMETERS
Max platform height
18.3 m 60 ft
Max working height
20.3 m 66 ft 7 in
Max horizontal reach
12.2 m
40 ft
Max up-and-over height
7.8 m 25 ft 7 in
Overall length (stowed)
8.6 m 28 ft 3 in
Overall width (stowed)
2.28 m 7 ft 6 in
Overall height (stowed)
2.56 m 8 ft 5 in
Wheelbase 2.44 m 8 ft
Ground clearance 0.23 m 9.1 ft
Platform dimension (L×W×H)
1.83 m × 0.85 m × 1.1 m 6 ft ×2 ft 9 in ×3 ft 7 in
Tire size (spec/type)
Options
33×12-20 (solid, non-marking)
33×12-20 (solid)
33×12D610 (foam-filled)
33×12D610 (foam-filled, non-marking)
PERFORMANCE PARAMETERS
Max bearing capacity of platform
250 kg (unrestricted/2 persons &
tools)
551 lb (unrestricted/2 persons &
tools)
Turntable rotation angle/continuity
360 °/continuous
Platform rotation angle
160°
Max drive speed (stowed)
5 km/h
3.1 mph
Max drive speed (raised)
1.1 km/h
0.68 mph
Drive mode (drive×steer)
4WD×2WS
Gradeability
40%
Turntable tail-swing
0.2 m
8 in
Max allowable inclination angle
5°
Turning radius (inside)
3.48 m 11 ft 5 in
Turning radius (outside)
6.29 m 20 ft 8 in
Max allowable side force 400 N 90 lbf
IP rating
IP 54
