© Oct. 2022 7-6 GTZZ18J Operation Manual
OPERATING THE MACHINE
switch, the articulated boom shall extend
automatically after rising to the highest; Moving
downwards the articulated boom up/down switch,
the articulated boom shall descend automatically
after retracting in place.
2. Move the enable switch and meanwhile move
upwards/downwards the main boom up/down
switch to raise or lower the main boom.
3. Move the enable switch and meanwhile move
rightwards/leftwards the boom telescope switch to
extend or extract the main boom.
4. Move the enable switch and meanwhile move
downwards/upwards the turntable rotate switch to
rotate the turntable clockwise or anticlockwise.
5. Move the enable switch and meanwhile move
upwards/downwards the platform level switch to
level up or down the platform.
FALL HAZARD
The platform level switch can
only be used for slight leveling of
the platform, improper use may
cause the load/occupant to shift
or fall.
6. Move the enable switch and meanwhile move
upwards/downwards the platform rotate switch to
rotate the platform clockwise or anticlockwise.
7. Move the enable switch and meanwhile move
upwards/downwards the jib up/down switch to raise
or lower the jib boom.
8. Move the enable switch and meanwhile move
upwards/downwards the jib rotate switch to rotate
the jib boom anticlockwise or clockwise.
To drive:
The drive function cannot be enabled from the ground
controller.
To steer:
The steer function cannot be enabled from the ground
controller.
OPERATION FROM
PLATFORM
UNSAFE OPERATION HAZARD
• Unless in emergency situations,
do not operate the machine from
the ground controller when there
is any person on the platform.
• Do not operate the machine if any
control handle or switch does not
return to OFF position after
released.
COLLISION HAZARD
When operating the boom, ensure
the area around or under the platform
is free of persons or obstacles.
Before operation:
1. Make sure the battery is well-connected before
operating the machine.
2. Turn the Ground/Platform select switch on the
ground controller to Platform position.
3. Pull out the red emergency stop button on both the
ground controller and platform controller to ON
position.
To position platform:
1. Depress the foot switch and meanwhile push
forward/pull backward the main boom luffing/
turntable rotate proportional control handle to raise
or lower the main boom.
2. Depress the foot switch and meanwhile push
forward/pull backward the main boom telescoping
proportional control handle to retract/extend the
main boom.
3. Depress the foot switch and meanwhile move
upward/downward the articulated boom luffing
switch to raise or lower the articulated boom.
4. Depress the foot switch and meanwhile move
upward/downward the articulated boom telescoping
switch to extend/retract the articulated boom.
5. Depress the foot switch and meanwhile move the
main boom luffing/turntable rotate proportional
control handle to the left/right to rotate the turntable
clockwise or anticlockwise.
To Next Page
