GTZZ14EJ&16EJ Operation Manual 2-1 © Dec 2021
2 MACHINE COMPONENTS
Figure 2-1
Table 2-1
1.Work platform 12.Upper foldable boom 23. Drive reducer
2. Foot switch 13. Main lift cylinder 24.Main power switch
3.Manual storage container (optional) 14. Cable track system 25.Lower foldable boom
4. AC Power Socket 15. Upper connector 26. Chassis assembly
