OPERATING THE MACHINE
GTZZ14EJ&16EJ Operation Manual 7-3 © Dec 2021
Figure 7-2 Position of least backward stability
1. Foldable boom fully folded;
2. Main boom fully retracted and fully extended;
3. Jib fully elevated;
4. Turntable rotated 90° ;
5. The machine will tip over in the direction as indicated by the arrow if overloaded or operated beyond the limits
of the maximum operating slope.
EMERGENCY STOP
1. Push the emergency stop button on the platform
controller to OFF, and all functions under the control
of the platform controller will get inoperative.
2. Push the emergency stop button on the ground
controller to OFF, and all functions under the control
of the ground and platform controllers will get
inoperative.
3. Push the power off switch at the left side of the
chassis to OFF, and the system power will be
disconnected and all functions will get inoperative.
The power off switch is located as shown in the
below figure.
