1 MACHINE SPECIFICATIONS
Table 1-1 GTZZ14EJ specifications
MEASURE
AB14EJ (METRIC) AB460EJ (IMPERIAL)
DIMENSION PARAMETERS
Max platform height
14 m 45 ft 11 in
Max working height
16 m 52 ft 6 in
Max horizontal reach 7.6 m 24 ft 11 in
Max up and over height
7.8 m 25 ft 7 in
Overall length (stowed)
6 m 19 ft 8 in
Overall width (stowed)
1.73 m 5 ft 8 in
Overall height (stowed)
2 m 6 ft 7 in
Wheelbase 1.9 m 6 ft 3 in
Ground clearance 0.22 m 8.7 in
Tire size (spec / type)
Optional
250–15 (non-marking)
250–15 (solid)
240/55D17.5/foam-filled
240/55D17.5/foam-filled, non-marking
27×10.5-15 (off-road, splayed, foam-filled)
27×10.5-15 (off-road, splayed, non-marking, foam-filled)
Platform dimension (L×W×H)
Optional
1.45×0.85×1.1 m
1.83x 0.85 x 1.1 m
Optional
57×33.5×43 in
72×33.5×43 in
PERFORMANCE PARAMETERS
Platform capacity
230 kg (unrestricted / 2
persons&tools)
507 lb (unrestricted / 2
persons&tools)
Turntable rotation / continuous 355° / uncontinuous
Platform rotation 160°
Max drive speed (stowed)
5.2 km/h
3.2 mph
Max drive speed (raised)
0.8 km / h
0.5 mph
Drive mode (drive×steer)
2WD×2WS
Gradeability
30% / 17°
Turntable tailswing
0 m
0 in
Max allowable inclination 5°
Turning radius (inside)
1.15 m 3 ft 9.2 in
Turning radius (outside)
3.51 m 11 ft 6.2 in
