Sinoboom AB520EJ - GTZZ16 EJ Model Specifications

© Dec 2021 1-2 GTZZ14EJ&16EJ Operation Manual
MACHINE SPECIFICATIONS
Table 1-1 GTZZ14EJ specifications (continued)
MEASURE
AB14EJ (METRIC) AB460EJ (IMPERIAL)
Max allowable side force 400 N 90 lbf
Max operating noise level
72dB
IP grade
IP54
POWER PARAMETERS
Engine (rated power, rated rpm) 5kW, 48VAC
Hydraulic tank capacity 40 L 8.8 gal (UK) / 10.6 gal (US)
Fuel tank capacity 52 L 11.4 gal (UK) / 13.7 gal (US)
Hydraulic system pressure 21 MPa 3045 Psi
Battery (number×voltage, capacity)
Optional
8×6V, 390Ah
2×24V, 315Ah
System voltage
48 VDC
Control voltage 12 VDC
GROUND BEARING DATA
Max tire load
3580 kg
7893 lb
Tire contact pressure
724.9 725 KPa
105.2 psi
ENVIRONMENT REQUIREMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280 ft
Allowable ambient temperature
(lead-acid battery)
-10℃～40℃ 14℉～104℉
Allowable ambient temperature (-
lithium battery)
-20℃～40℃ -4℉～104℉
Max allowable RH
90%
Storage environment
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gas, inflammables and explosives.
WEIGHT
Gross weight (unladen) 7100 kg
15653 lb
Table 1-2 GTZZ16EJ specifications
MEASURE
AB16EJ (METRIC) AB520EJ (IMPERIAL)
DIMENSION PARAMETERS
Max platform height
15.7 m 51 ft 6 in
Max working height
17.7 m 58 ft 1 in
