MACHINE SPECIFICATIONS
GTZZ14EJ&16EJ Operation Manual 1-3 © Dec 2021
Table 1-2 GTZZ16EJ specifications (continued)
MEASURE
AB16EJ (METRIC) AB520EJ (IMPERIAL)
Max horizontal reach 9.3 m 30 ft 6 in
Max up and over height
7.8 m 25 ft 7 in
Overall length (stowed)
6.8 m 22 ft 4 in
Overall width (stowed)
1.9 m 6 ft 3 in
Overall height (stowed)
2 m 6 ft 7 in
Wheelbase 1.9 m 6 ft 3 in
Ground clearance 0.22 m 8.7 in
Tire size (spec / type)
Optional
250–15 (non-marking)
250–15 (solid)
240/55D17.5/foam-filled
240/55D17.5/foam-filled, non-marking
27×10.5-15 (off-road, splayed, foam-filled)
27×10.5-15 (off-road, splayed, non-marking, foam-filled)
Platform dimension (L×W×H)
Optional
1.45 x 0.85 x 1.1 m
1.83 × 0.85 × 1.1 m
Optional
57×33.5×43 in
72 × 33.5 × 43 in
PERFORMANCE PARAMETERS
Platform capacity
230 kg (unrestricted / 2
persons&tools)
507 lb (unrestricted / 2
persons&tools)
Turntable rotation / continuous 355° / uncontinuous
Platform rotation 160°
Max drive speed (stowed)
5.2 km/h
3.2 mph
Max drive speed (raised)
0.8 km / h
0.5 mph
Drive mode (drive×steer)
2WD×2WS
Gradeability
30% / 17°
Turntable tailswing
50 mm
2 in
Max allowable inclination 5°
Turning radius (inside)
0.7 m 2 ft 3.5 in
Turning radius (outside)
3.31 m 10 ft 10.3 in
Max allowable side force 400 N 90 lbf
Max operating noise level
72dB
IP grade
IP54
POWER PARAMETERS
Engine (rated power, rated rpm) 5kW, 48VAC
Hydraulic tank capacity 40 L 8.8 gal (UK) / 10.6 gal (US)
Fuel tank capacity 52 L 11.4 gal (UK) / 13.7 gal (US)
