© Dec 2021 7-2 GTZZ14EJ&16EJ Operation Manual
OPERATING THE MACHINE
Figure 7-1 Position of least forward stability
1. Foldable boom fully folded;
2. Main boom elevated horizontal and fully extended;
3. Jib elevated horizontal;
4. Turntable rotated 90°;
5. The machine will tip over in the direction as indicated by the arrow if overloaded or operated beyond the limits
of the maximum operating slope.
