© Mar. 2022 2-2 GTTZ10EJ Operation Manual
MACHINE COMPONENTS
Figure 2-1
Table 2-1
1. Platform controls
12. Warning light
23. Power unit
2. Work platform
13. Ground controls
24. Counterweight
3. Manual storage container (optional)
14. Turntable cover, LH
25. Steering cylinder
4. Jib boom
15. Turntable cover, RH
26 Cable track
5. Jib boom cylinder
16. Power-off switch
27. Slewing unit
6. 4th telescopic boom 17. Charger plug cable
28. Chassis
7. 3th telescopic boom 18. Front steering wheel 29. Charger
8. 2nd telescopic boom 19. Pothole guard plate
30. Level switch
9. 1st telescopic boom
20. Drive reducer 31. Level switch
10. Base boom
21. Rear driving wheel
11. Telescoping mechanism 22. Battery
Machine positions
Stowed position:
The machine comes in stowed position when the
main boom is fully lowered.
Non-operating position:
The machine remains in non-operating position when
the down limit switch does not disengage.
Operating/raised position:
The machine comes in operating/raised position
when the platform is raised until the down limit switch
disengages.
