APPENDIX 1: SYMBOLS AND
DESCRIPTION
CHART of SYMBOLS
Read maintenance
manual
Anchorage point for 1
person only
Read operation manual Add lubricant Crushing hazard-
Please wear work
shoes
Wind speed Chemical burn hazard Choke the wheels Release the brake Wind
Noise level Burn hazard Keep a safe distance
from high temperature
Pull out to turn on
Push in to turn off
Alarm sounds
Hot or high pressure
fluid ejection hazards
Hydraulic oil level - low
level
Hydraulic oil level -
high level
Temperature
Replace with tires of
the same
specifications
Only trained
maintenance
personnel can access
the bulkhead
Electrocution hazard
on platform
Electrocution hazard
on the ground and
platform
Keep a safe distance
from the electric
conductors
Tip-over hazard-Avoid
uneven ground
Tip-over hazard-Avoid
uneven ground
Tip-over hazard-Never
use machine in strong,
gusty wind
Tip-over hazard-Never
use machine in strong,
gusty wind
Tip-over hazard-Never
push or pull objects
outside platform
Tip-over hazard-Never
suspend objects from
platform
