© Jun 2022 6-10 TB24 Plus&26J Plus Operation Manual
PRE-OPERATION FUNCTION TEST
Note: The electrically controlled engine can be
preheated automatically.
Emergency stop button
1. Push in the emergency stop button on the
platform controller to OFF position and move the
engine start switch. The engine should fail to start
and all functions should be inoperative.
2. Pull out the emergency stop button on the
platform controller to ON position and move the
engine start switch. The engine should start
normally.
3. Push in the emergency stop button on the ground
controller to OFF position and pull out the
emergency stop button on the platform controller
to ON position, and then move the engine start
switch, the engine should fail to start and all
functions should be inoperative.
Engine high/low speed select switch
Move the engine high/low speed select switch, the
engine should be switched between high/low speed.
Drive function
1. Depress the foot switch and move forward the
Drive/Steer control handle, the machine shall
drive forward smoothly without noticeable impact
in startup; when the handle is released, the
machine should be held reliably.
2. Depress the foot switch and move backward the
Drive/Steer control handle, the machine should
drive reverse smoothly without noticeable impact
in startup; when the handle is released, the
machine should be held reliably.
Note: The drive speed is in direct proportion to the
stroke of control handle.
Steer function
1. Depress the foot switch and move forward the
Drive/Steer control handle, and press the left side
of the thumb rocker switch on top of the drive
control handle, the machine should steer left.
2. Depress the foot switch and move forward the
Drive/Steer control handle, and press the right
side of the thumb rocker switch on top of the drive
control handle, the machine should steer right.
Note: The steering drive speed is in direct proportion to
the stroke of control handle.
Drive high/low speed select switch
TIPPING HAZARD
The machine must drive at low speed
when not on a level surface.
The drive speed of the machine in stowed position
can be switched between high/low speed by moving
the drive high/low speed select switch.
Turntable rotate
1. Depress the foot switch and move leftwards the
main boom lift/turntable rotate proportional control
handle, the turntable should rotate clockwise.
2. Depress the foot switch and move rightwards the
main boom lift/turntable rotate proportional control
handle, the turntable should rotate
counterclockwise.
Note: The turntable rotate speed is in direct proportion
to the stroke of control handle.
Main boom up/down
∅52
∅22
∅35
∅55
4X ∅7
∅12.5
R2.5
∅22
4XR6
235
98
78
220
4065
57.540.5
11.2
7.5
1
2
3
4
5
6
7
1
2
3
4
5
6
7
技术要求
1、PVC 不干胶自粘面膜。
2、面膜底色为黑色。
3、颜色要求：上下台切换图标中底座颜色为蓝色，转换方向图案黄色，叉子及平台颜色为黄色，
升降切换图标底座颜色为蓝色，上升图案黄色，下降图案为红色，
急停开关图标底色为黄色、字体颜色为红色,小时指示图标为绿色。
4、所有孔尺寸公差为±0.1；
1
1
2
2
A A
B B
50.0
88.0
更改文件号
审 核
工 艺
处数
标记
设 计
日 期
共 页
签 字
标准化
日期
图 样 标 记
第 页
比 例
重 量
0.45
李申奥
银友国
刘奇志
2018.11.15
1
刘晓
面膜
101013060005
1:1
1
101013060005
