© Jun 2022 6-16 TB24 Plus&26J Plus Operation Manual
PRE-OPERATION FUNCTION TEST
TESTING THE WEIGHING
SYSTEM
Before the test, move the boom fully up and down and
telescope in and out for at least twice to ensure the
pulley and track are adequately lubricated.
Table 6-6
MODELS TEST RESULTS
TB24 Plus&26J
Plus (KG mode)
Under restricted configuration:
When the load does not exceed 454kg (1000 lb) , ensure that the platform is able to lift to the
highest position.
when the load exceeds 454kg (1000 lb) , the buzzer will sound continuously, the overload
indicator light will flash, the display screen will indicate platform overload, all motion functions
are restricted and will not resume until the excessive load is removed.
Under unrestricted configuration:
the load does not exceed 300kg (661 lb) , ensure that the platform is able to lift to the highest
position.
when the load exceeds 300kg (661 lb) , the buzzer will sound continuously, the overload
indicator light will flash, the display screen will indicate platform overload, all motion functions
are restricted and will not resume until the excessive load is removed.
TB24 Plus&26J
Plus (non-KG
mode)
Under restricted configuration:
When the load does not exceed 454kg (1000 lb) , ensure that the platform is able to lift to the
highest position.
When the load exceeds 454kg (1000 lb) , the buzzer will sound continuously, the overload
indicator light will flash, the display screen will indicate platform overload, some motion
functions will be restricted, but boom retracting, turntable rotating and boom lowering after fully
retracted is allowed. All motion functions will not resume until the excessive load is removed.
Under unrestricted configuration:
When the load does not exceed 300kg (661 lb) , ensure that the platform is able to lift to the
highest position.
When the load exceeds 300kg (661 lb) , the buzzer will sound continuously, the overload
indicator light will flash, the display screen will indicate platform overload, some motion
functions will be restricted, but boom retracting, turntable rotating and boom lowering after fully
retracted is allowed. All motion functions will not resume until the excessive load is removed.
