OPERATING THE MACHINE
2. Move the enable switch and meanwhile move
rightwards/leftwards the boom telescope switch to
extend or retract the main boom.
3. Move the enable switch and meanwhile move
rightwards/leftwards the turntable rotate switch to
rotate the turntable clockwise or counterclockwise.
4. Move the enable switch and meanwhile move
upwards/downwards the platform level switch to
level up or down the platform.
FALL HAZARD
The platform level switch can
only be used for slight leveling of
the platform; improper use may
cause the load/occupant to shift
or fall.
5. Move the enable switch and meanwhile move
upwards/downwards the platform rotate switch to
rotate the platform clockwise or anticlockwise.
6. Move the enable switch and meanwhile move
upwards/downwards the jib up/down switch to raise
or lower the jib boom (TB26J Plus only).
To drive:
The drive function cannot be enabled on the ground
controller.
To steer:
The steer function cannot be enabled on the ground
controller.
OPERATION FROM
PLATFORM
UNSAFE OPERATION HAZARD
• Unless in emergency situations,
do not operate the machine from
the ground controller when there
are personnel in the platform.
• Do not operate the machine if any
control handle or switch is not
returned to off position after being
released.
COLLISION HAZARD
When operating the boom, be sure
the area around or under the platform
is free of persons or obstacles.
Before operation:
1. Make sure the battery is properly connected before
operating the machine.
2. Turn the Ground/Platform select switch on the
ground controller to Platform.
3. Pull out the red emergency stop buttons on both the
ground and platform controllers to the ON position.
4. Turn the key switch on the ground controller to the
ON position.
5. Move the engine start switch (not exceeding 15s)
on the platform controller to start the engine.
NOTICE
• If the engine fails to get started immediately,
do not keep starting the engine for too long; if
a restart still fails, allow the starter to cool
down for 2–3min; if the engine still fails to get
started after several attempts, please
reference the Maintenance Manual.
• Before applying any load, warm up the engine
by running it at low speed for 3–5min.
• Do not start the engine with the foot switch
depressed.
• If the machine shuts down unexpectedly due
to the engine malfunction, be sure to correct
the fault before restarting the engine.
To position platform:
1. Depress the foot switch and meanwhile move
forward/backward the main boom lift/turntable
rotate control handle to raise or lower the main
boom.
2. Depress the foot switch and meanwhile move
backward/forward the main boom telescope/jib
rotate control handle to extend or retract the main
boom.
3. Depress the foot switch and meanwhile move
leftwards/rightwards the main boom lift/turntable
rotate control handle to rotate the turntable
clockwise or counterclockwise.
4. Depress the foot switch and meanwhile move
upwards/downwards the platform level switch to
level up/down the platform.
