1 MACHINE SPECIFICATIONS
Table 1-1 TB24 Plus specifications
MEASURE
TB24 Plus (METRIC) TB800 Plus (IMPERIAL)
DIMENSION
Max platform height
24.4m 80ft 0.6in
Max working height
26.4m 86ft 7in
Max horizontal reach (restricted/
unrestricted)
18.43m/20.74m 60ft 5.6in/68ft 0.5in
Overall length (stowed)
11.55m 37ft 11in
Overall length (transport)
11.55m 37ft 11in
Overall width (stowed)
2.49m 8ft 2in
Overall width (transport)
2.49m 8ft 2in
Overall height (stowed)
2.88m 9ft 5in
Overall height (transport)
2.88m 9ft 5in
Wheelbase 3m 9ft 10in
Ground clearance 0.46m 1ft 6in
Tire size (spec/type)
Options
385/65-22.5 (foam-filled)
385/65-24/10.00 (solid)
385/45-28 (foam-filled, non-marking)
15-625 (foam-filled)
385/65-24/10 (solid, non-marking)
Platform dimension (L×W×H)
Options
1.45×0.85×1.1 m
1.83×0.85×1.1 m
2.44×0.91×1.1 m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
8ft×3ft×3ft 7in
PERFORMANCE
Rated platform capacity (restricted/
unrestricted)
454kg/300kg
1,000lb/661lb
Max number of occupants on
platform (restricted/unrestricted)
3P/2P
Turntable rotation/continuity
360°/continuous
Platform rotation 160°
Max drive speed (stowed)
4.8km/h
3mph
Max drive speed (raised)
1.1km/h
0.68mph
Drive mode (drive×steer)
4WD×2WS
Gradeability
45%/24°
