MACHINE SPECIFICATIONS
Table 1-1 TB24 Plus specifications (continued)
MEASURE
TB24 Plus (METRIC) TB800 Plus (IMPERIAL)
Turntable tail-swing
1.45m
4ft 9in
Max allowable inclination 5°
Turning radius (inside)
3.65m 12ft
Turning radius (outside)
6.91m 22ft 8in
Max allowable side force 600N/400N 135lbf/90lbf
Max operating noise level
82dB
IP rating
IP65
POWER
Engine (rated power/rated rpm/
spec/brand/emission standard)
54kW/2400rpm/QSF2.8t3TC72/Cummins/China Stage 3
55.4kW/2600rpm/TD2.9 L4/Deutz/Euro Stage 5
55.4kW/2600rpm/TD2.9 L4/Deutz/US Stage 4
55.4kW/2400rpm/TD2011 L04i/Deutz/US Stage 3
36.8kW/2500rpm/WP3.2/Weichai/China Stage 4
36.8kW/2200rpm/YCF3050/Yuchai/China Stage 4
Hydraulic tank capacity 190L 41.8gal (UK)/50.2gal (US)
Oil Capacity of hydraulic tank
160L
35.2gal (UK)/42.3gal (US)
Fuel tank capacity
160L
35.2gal (UK)/42.3gal (US)
Hydraulic system pressure 28MPa 4,061Psi
Battery (number×voltage, capacity) 2×12V, 110Ah
System voltage
12 VDC
Control voltage 12 VDC
GROUND BEARING DATA
Max tire load
9,620kg
21,208lb
Pressure against ground 730kpa
105.9Psi
ENVIRONMENT
Max allowable wind speed 12.5m/s 28mph
Max allowable altitude
1,000m 3,280ft
Allowable ambient temperature
(lead-acid battery)
-10℃～40℃ 14℉～104℉
Max allowable RH
90%
Storage environment
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gas, inflammables and explosives.
WEIGHT
Gross weight (unladen) 16,530kg
36,442lb
