MACHINE SPECIFICATIONS
TB24 Plus&26J Plus Operation Manual 1-3 © Jun 2022
Table 1-2 TB26J Plus specifications
MEASURE
TB26J Plus (METRIC) TB860J Plus (IMPERIAL)
DIMENSION
Max platform height
26.3m 86ft 3in
Max working height
28.3m 92ft 10in
Max horizontal reach (restricted/
unrestricted)
17.91m/20m 58ft 9in/65ft 7in
Overall length (stowed)
12.5m 41ft
Overall length (transport)
10.25m 33ft 8in
Overall width (stowed)
2.49m 8ft 2in
Overall width (transport)
2.49m 8ft 2in
Overall height (stowed)
2.88m 9ft 5in
Overall height (transport)
2.96m 9ft 9in
Wheelbase 3m 9ft 10in
Ground clearance 0.46m 1ft 6in
Tire size (spec/type)
Options
385/65-22.5 (foam-filled)
385/65-24/10.00 (solid)
385/45-28 (foam-filled, non-marking)
15-625 (foam-filled)
385/65-24/10 (solid, non-marking)
Platform dimension (L×W×H)
Options
1.45×0.85×1.1m
1.83×0.85×1.1m
2.44×0.91×1.1m
Options
4ft 9in×2ft 9in×3ft 7in
6ft×2ft 9in×3ft 7in
8ft×3ft×3ft 7in
PERFORMANCE
Rated platform capacity (restricted/
unrestricted)
454kg/300kg
1,000lb/661lb
Max number of occupants on
platform (restricted/unrestricted)
3P/2P
Turntable rotation/continuity
360°/continuous
Platform rotation 160°
Max drive speed (stowed)
4.8km/h
3mph
Max drive speed (raised)
1.1km/h
0.68mph
Drive mode (drive×steer)
4WD×2WS
Gradeability
45%/24°
Turntable tail-swing
1.45m
4ft 9in
Max allowable inclination 5°
Turning radius (inside)
3.65m 12ft
Turning radius (outside)
6.91m 22ft 8in
