MACHINE SPECIFICATIONS
Table 1-2 TB26J Plus specifications (continued)
MEASURE
TB26J Plus (METRIC) TB860J Plus (IMPERIAL)
Max allowable side force 600N/400N 135lbf/90lbf
Max operating noise level
82dB
IP rating
IP65
POWER
Engine (rated power/rated rpm/
spec/brand/emission standard)
54kW/2400rpm/QSF2.8t3TC72/Cummins/China Stage 3
55.4kW/2600rpm/TD2.9 L4/Deutz/Euro Stage 5
55.4kW/2600rpm/TD2.9 L4/Deutz/US Stage 4
55.4kW/2400rpm/TD2011 L04i/Deutz/US Stage 3
36.8kW/2500rpm/WP3.2/Weichai/China Stage 4
36.8kW/2200rpm/YCF3050/Yuchai/China Stage 4
Hydraulic tank capacity
190L
41.8gal (UK)/50.2gal (US)
Oil Capacity of hydraulic tank
160L
35.2 gal (UK)/42.3 gal (US)
Fuel tank capacity
160 L
35.2 gal (UK)/42.3 gal (US)
Hydraulic system pressure 28MPa 4061Psi
Battery (number×voltage, capacity) 2×12V, 110Ah
System voltage
12 VDC
Control voltage 12 VDC
GROUND BEARING DATA
Max tire load
9,620kg
21,208 lb
Pressure against ground 730kpa
105.9 Psi
ENVIRONMENT
Max allowable wind speed 12.5m/s 28mph
Max allowable altitude
1,000m 3,280ft
Allowable ambient temperature
(lead-acid battery)
-10℃～40℃ 14℉～104℉
Max allowable RH
90%
Storage environment
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gas, inflammables and explosives.
WEIGHT
Gross weight (unladen) 17,000kg
37,479lb
Note:
a) The platform height plus the operator height (taken as 2m/6ft 7in) is the working height.
b) The ground bearing data is approximate value, not factoring different options, thus it serves only in adequately safe
conditions.
c) In different areas, hydraulic oil, engine oil, coolant, fuel and lubrication should be added in accordance with the
environmental temperature.
d) In cold weather, auxiliary devices are needed to start the machines.
e) Rated platform capacity refers to the rated load of the platform, including the loads of persons, materials, tools, platform
accessories and other objects borne by the platform.
