DECALS/NAMEPLATES INSPECTION
TB24 Plus&26J Plus Operation Manual 10-9 © Jun 2022
No. Part No.
Description Qty.
Remarks
105063103009
Decals (CE-Imperial)-TB24 Plus
1
105064103010
Decals (CE-Imperial)-TB26J Plus
1
1 104011100002
Decal-Lifting points
6
2 104011100014
Decal-Explosion hazard
1
3 105045103002 LOGO-White sticker 2
4 104011100006 Decal-Bulkhead overhaul 2
5 104011100013 Decal-Electrocution hazard 1
6 104011100007
Decal-Tipping hazard
2
7 104011100020
Decal-General safety
2
8 105001100050 Decal-Contact information 1
9 104011100022 Decal-Turntable rotation lock 1
10 104011100011 Decal-Crush hazard 4
11 105057103001 LOGO-SINOBOOM 1
12
105063103004
Decal-TB800 Plus (large)
1 TB24 Plus
105064103007
Decal-TB860J Plus (large)
1 TB26J Plus
13 104011100012 Decal-Fall hazard 1
14 104011100001
Decal-Tipping hazard
4
15 105064103008
Decal-Wheel load 9620kg
4
16 105001100056
Nameplate-CE (TB)
1
17 215050000012 Blind rivet 4×8-ZnD 4
18 104011100005
Decal-Explosion hazard
1
19
105063103003
Decal-TB800 Plus (small)
2 TB24 Plus
105064103006
Decal-TB860J Plus (small)
2 TB26J Plus
20 104011100008 Decal-Noise 82dB 1
21 104011100018 Decal-Burn hazard 1
22 104011100016
Decal-Emergency stop switch
1
23 101016100030
Decal-Lanyard anchorage points
2
24 105071103005
Decal-Tipping hazard (600N)
1
25 105021100003
Decal-Tipping hazard
1
26 104011100019 Decal-Crush hazard 1
27 104011100009 Decal-Read manuals 1
28 104011100017 Decal-Foot switch 1
29 104011100021 Decal-Crush hazard 4
30 105049103002
Decal-Rated load 454kg
1
31 216060000002
Yellow-Black caution stripe
4
32 104011100003
Decal-Hydraulic oil level
1
