Sirona C5+ Turn - Dimensions of the C5 + Turn 1:20

Sirona Dental Systems GmbH 2 Dimensions, technical data
Installation Requirements C5
+
, C5
+
Tur n
60 27 978 D3415
D3415.021.03.08.02
21
båÖäáëÜ
2.2 Dimensions of the C5
+
Turn 1:20
250
9 7/8”
1600
63”
1600
63”
2500
98 7/16”
350
13 3/4”
Recommended distances from cabinet or wall.
Hazard warning:
The here mounted lamp, the dentist element /
with tray (option) have a wider swivelling
range than the distances indicated!
Center floor opening
