Sirona C8+ - C8 + 1:20

2 Dimensions, technical data Sirona Dental Systems GmbH
2.1 C8
+
1:20 Installation Requirements C8
+
60 28 000 D3417
16 D3417.021.04.09.02
Recommended distances from cabinet or wall.
2.1 C8
+
1:20
1700
67”
1300
51 3/16”
2500
98 7/16”
250
9 7/8”
!
!
Hazard warning:
The here mounted lamp and the dentist
element have a wider swivelling range
than the distances indicated!
Center floor opening
250
9 7/8”
