2 Dimensions, technical data C8
+
1:20 Sirona Dental Systems GmbH
2.6 C8
+
Tu r n 1 : 2 0 Installation Requirements C8
+
60 28 000 D3417
32 D3417.021.04.09.02
Equal working conditions for right-handers and left-handers: Position for
left-handers
C8
+
Turn 1:20
Center floor opening
1050
41 3/8”
1050
41 3/8”
1600
63”
1600
63”
17°
2750
108 1/4”
1234
48 1/2”
250
9 7/8”
250
9 7/8”
