SISTEMATICA EASY User Manual

TECHNICAL FEATURES
Manufacturer: Sistematica S.r.l.
Protection degree: IP66 (CNTR4 = IP68)
Operating temperature: -20°C ÷ +55°C
Supply voltage: 10/30V ±10%
Typical absorption at rest: 30mA a 10V e 30V
Reverse polarity protection of the battery
Microprocessor control
Receiver category (EN 300-220-1): 2
Radio transmission features:
• Modulation: GFSK
• Data rate: 50 KBaud
• Output power: max 10 dBm nominal
• Frequency band:
433,29 MHz – 434,49 MHz (max 10mW)
865,2 MHz - 867,8 MHz (max 25mW)
915,0 MHz - 918,0 MHz (max 92,73 dB ΜV7m)
CNTR 4 (CNTRNIMBLE/PLUS)
Number of outputs: up to 4
Number of digital inputs: up to 1
Maximum current available for each channel: 5A
Maximum total deliverable current: 10A
Integrated antenna
RADIOCAN
Main connector: M12
Communication interface CANBUS: J1939 or proprietary
protocol 4-bit CanBus (up to 16 supported nodes)
Internal antenna
CNTR 8
Dimensions (mm): 108 x 110 x 44
Number of outputs: up to 8
Number of digital inputs: up to 1
Maximum current available for each channel: 5A
Maximum total deliverable current: 10A
Main connector: FCI SICMA 24 Header pin
Internal antenna
RECEIVERS
85
