It is not possible to control the outputs simultaneously
from the emergency keypad and the remote control.
LIGHT GUIDE
The Light Guide option on the receivers help to signal the functioning of
certain operations.
GREEN LED: power and radio reception.
YELLOW LED: system pairing.
RED LED: anomaly warning.
EMERGENCY KEYBOARD
CNTR8 - CNTR20
The emergency keypad allows the use of the system in the event that the
batteries of the handheld are exhausted, in the event that the handheld
is lost or in the event that, for any reason, it is not possible to control the
outputs from the transmitter.
OPERATION
1. Power up the receiver and wait 3-4 seconds.
2. To execute a command, press the ENABLE (= START) key together with the
desired numeric key on the emergency keypad.
The keyboard has the handheld’s numbering (for the CNTRNIMBLEPLUS there
are only two simplified function buttons).
91
