FUEL AND OIL
520001899-003_a
TYPICAL
1. Fuel tank cap
4. Insert the spout into the filler neck.
5. Pour fuel slowly so that air can escape from the tank and prevent
fuel flow back. Be careful not to spill fuel.
6. Stop filling when the fuel reaches the bottom of filler neck. Do
not overfill.
WARNING
Never top up the fuel tank before p lacing the vehicle in a warm
area. As temperature increases, fuel expands and may over-
flow.
7. Fully tighten fuel reservoir cap clockwise.
WARNING
Always wipe off any small fuel spi llage from the vehicle. If a
major spillage occurs, remove side panels to remove fuel va-
pors from engine compartment before starting.
NOTE: Do not sit or lean on seat when fuel tank cap is not properly
installed.
160
