CONTROLS, INSTRUMENTS AND EQUIPMENT
CAUTION
– It is HIGHLY recommended to use g loves and NO T mitts when
using the finger throttle position.
– It is not recommended to use the finger throttle position while
riding in dense off trail areas.
The procedure to go back to the thumb throttle position is the reverse
of the one shown above.
3) Brake Lever
Brake lever is located on the LH side of handlebar.
When squeezed, brake is applied. When released, it automatically
returns to the rest. Braking effect is proportional to the pressure
applied on the lever and to the type of terrain and its snow coverage.
mmo2014-004-001_a
TYPICAL
1. Brake lever
2. To apply brake
__________________
77
