Ski-Doo REV Series User Manual

This adjustable drive pulley allows setting maximum engine RPM in
the vehicle to maintain maximum power.
Calibration screws should be adjusted so that actual maximum en-
gine RPM in vehicle matches with the maximum horsepower RPM.
NOTE: Use precision digital tachometer for engine RPM adjustment.
NOTE: The adjustment has an effect on high RPM only.
Calibration screw has a notch on top of its head.
1
A33D19A
1. Notch
Thereare6positionsnumbered1to6. OnTRAdrivepulley,note
that in position 1 the number is substituted by a dot (due to its loca-
tion on casting).
190
_________________________

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
