Ski-Doo REV Series User Manual

A16D0GA
1
TRA DRIVE PULLEY
1. Position 1 (not numbered)
Each position modifies maximum engine RPM by about 200 RPM.
Lower position numbers decrease engine RPM in steps of 200 RPM
and higher position numbers increase it in steps of 200 RPM.
Example:
Calibration screw is set at position 4 and is changed to position 6.
So maximum engine RPM is increased by 400 RPM.
Adjustment
Just loosen locking nut enough to pull calibration screw partially out
and adjust to desired position. Do not completely remove the locking
nut. Torque locking nuts to 10 N•m(89lbf•
in).
CAUTION: Do not completely remove calibration screw other-
wise internal washers will fall off. Always adjust all 3 calibration
screwsandmakesuretheyareallsettothesameposition.
_________________________
191

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
