Ski-Doo REV Series User Manual

9
A35A04B
10
1
2-364
8
5
7
MODELS WITH TACHOMETER ONLY
1. Brake/parking brake pilot lamp (red)
2. Reverse pilot lamp
3. DESS pilot lamp
4. High beam pilot lamp (blue)
5. Oil pilot lamp
6. Low battery voltage pilot lamp
7. Engine management system (EMS) pilot lamp
8. Engine overheat warning lamp (red)
9. Mode Button
10. Multifunction display
Brake/Parking Brake Pilot Lamp (Red)
Lights when brake or parking brake is applied (with engine running).
Reverse Pilot Lamp
This pilot lamp will light up when reverse is selected.
DESS Pilot Lamp
This lamp will light up to confirm DESS status. Refer to previous
paragraphs for description.
High Beam Pilot Lamp (Blue)
Lights when headlamp is on HIGH beam.
66
_________________________

Ski-Doo REV Series Specifications

General

Chassis	REV
Track Width	15 in
Fuel Capacity	10.6 gal
Seating Capacity	1
Reverse	Available on most models
Electric Start	Available on most models
