Oil Pilot Lamp
This pilot lamp will glow up when injection oil level is low. Stop ve-
hicle in a safe place then, replenish injection oil reservoir.
Low Battery Voltage Pilot Lamp
This lamp will light up to indicate a low battery voltage condition (on
so equipped models). See an authorized SKI-DOO dealer as soon as
possible.
Engine Management System (EMS) Pilot Lamp
This lamp will light up to indicate a trouble. Refer to TROU-
BLESHOOTING for trouble code meaning and remedy.
Engine Overheat Warning Lamp (Red)
If this lamp glows, reduce snowmobile speed and run snowmobile
in loose snow or stop engine immediately.
Mode Button
Depress mode button to change multifunction display. Each time en-
gine is started, display shows odometer. From that point depressing
mode button will change display for the trip meter.
Depressing mode button again will change display for the resetable
hourmeter. Push mode button again to return to odometer.
Push and hold mode button for 2 seconds to reset the tripmeter or
the resetable hourmeter depending on the one displayed.
Multifunction Display
Odometer
Odometer records the total distance travelled and displays it either
in miles or kilometers. Refer to CHANGE FROM ONE UNIT TO THE
OTHER for changing units.
Trip M ete r
Records distance travelled since it has been reset. Distance trav-
elled is displayed either in miles or kilometers. Refer to CHANGE
FROM ONE UNIT TO THE OTHER for changing units.
Resetable Hourmeter
Records engine running time in hours and minutes since it has been
reset.
Pushandholdmodebuttonfor2secondstoresetthehourmeter.
__________________________
67
