Ski-Doo SUMMIT 583 1997 - 2-Speed Gearbox

Section 04 TRANSMISSION
Sub-Section 08 (GEARBOX)
04-08-8
2-SPEED GEARBOX
Grand Touring 500/583
A03D17S
15 N•m
(133 lbf•in)
7
8
5
28
31
40
48 N•m
(35 lbf•ft)
Loctite
271
6
16
17
32
33
34
37
38
5 N•m
(44 lbf•in)
35
36
29 N•m
(21 lbf•ft)
Loctite
242
Loctite
242
27
Grease
25
14
Loctite
271
26
15
18
19
20
21
22
23
24
10
9
11
12
13
Grease
4
29
PARTS
FLAT RATE
