Section 08 BODY/FRAME
Sub-Section 02 (BODY)
08-02-3
BELT GUARD
Disassembly and Assembly
NOTE:
For additional information (ex.: ex-
ploded view) refer to the correspondent
parts catalog.
Inspection
All Models
Check belt guard and/or pulley guard mounting
bosses, clips and retainers for wear.
WIRING HARNESS
CABLES
PIPING
NOTE:
Refer to proper
Parts Catalog
to find
suitable clip part numbers.
◆
WARNING
Engine should be running only with belt
guard and/or pulley guard well secured in
place.
◆
WARNING
Ensure all terminals are properly crimped on
the wires and that all connector housings
are properly fastened. Keep wires away
from any rotating, moving, heating and vi-
brating parts. Use proper fastening devices
as required.
◆
WARNING
Before installation, ensure that all cables are
in perfect condition. Properly install the ca-
ble ends and secure them in place. Pay at-
tention to route them properly, away from
any rotating, moving, heating, or vibrating
parts.
◆
WARNING
Always ensure that the fuel, vent, primer,
impulse, injection oil and rotary valve oil
lines are properly fixed to their connectors,
that they are not perforated or kinked and
that they are properly routed away from any
rotating, moving, heating or vibrating parts.
Also check for leaks. Replace if required.
