Section 05 ELECTRICAL
Sub-Section 02 (WIRING DIAGRAMS)
05-02-1
WIRING DIAGRAMS 2
hal. = halogen
CHART CODES
Wiring Color Code
The first color of a wire is the main color, second
color is the stripe.
Example: YL/BK is a YELLOW wire with a BLACK
stripe.
MODEL
WIRING
DIAGRAM
PAGE
HEADLIGHT
(watt)
TAILLIGHT
(watt)
ELECTRICAL
SYSTEM
OUTPUT
(watt)
MX Z 440 F Annex 1 60/55 hal. 8/27 240
MX Z 440/583/670 Annex 2 60/55 hal. 8/27 220
Formula 500 DELUXE Annex 3 60/55 hal. 8/27 220
Formula 500/583
Summit 500/583/670
Annex 4 60/55 hal. 8/27 220
Formula Z Annex 5 60/55 hal. 8/27 220
Grand Touring 550/583 Annex 6 60/55 hal. 8/27 220
Skandic WT/SWT Annex 7 60/55 hal. 8/27 240
Skandic WT LC Annex 8 60/55 hal. 8/27 240
COLOR CODE
BK — BLACK
WH — WHITE
RD — RED
BL — BLUE
YL — YELLOW
GN — GREEN
GY — GREY
VI — VIOLET
OR — ORANGE
BR — BROWN
