29
NMEA output setup
NMEA 0183 messages can be output on three
serial ports; use the tick-boxes to select which
messages are sent out on which serial port.
Each serial port can output any number of the
available messages. See section 8.4 for a
description of the supported output NMEA 0183
messages.
Touch the frame with indicated baud rate
value – to change the baud rate. Select one
out of:
2400; 4800; 9600; 19200; 38400; 57600; 115200
