SKYJACK, Page 46
February 2008
Mid Size & Full Size RT’s
Engine Powered
Section 2 - Operation Start Operation
2.10-11 Generator (If Equipped)
To start hydraulic generator:
1. On platform control console, select off/lift/drive
key switch to “
” lift position.
2. Depress and hold engine “ ” start pushbutton
until engine starts, then release. Do not overcrank
starter.
3. On auxiliary control console, select hydraulic
generator switch to energized position. Engine will
automatically switch to high throttle and generator
will start.
To restore normal operation:
Flip the switch to the off position. The generator 1.
will turn off.
NOTE
Activating any lift or outrigger functions,
changing the key switch setting, activating
the emergency stop or an engine stall will
turn off the generator. The platform may be
lowered during generator operation.
2.10-12 Electrical Inverter (If Equipped)
The inverter is operational with alternating current
available at all times when, and only when, the engine is
running at high throttle. Deselecting the high idle throttle
setting or stopping the engine will turn the inverter off.
To check status of inverter:
During routine operation, the on/off switch should 1.
remain in the on position. To prevent automatic
inverter operation when high throttle is activated,
slide the on/off switch on the inverter to the off
position.
Inverter state is indicated by the LEDs on the face 2.
of the inverter. A glowing green LED indicates
normal operation. If a fault occurs, the status
LEDs will indicate the area responsible. After
the fault condition is corrected, the inverter will
automatically reset itself.
2.10-13 Shutdown Procedure
1. Completely lower the platform.
2. On platform control console, push in “
”
emergency stop button.
3. Select off/lift/drive select key switch to “
” off
position and remove key.
WARNING
Ensure that you maintain three points of
contact when using the ladder to mount/
dismount the platform.
4. Use the ladder to dismount from platform.
5. On the engine tray post:
For diesel engine, push in off/on switch to “•
” off
position.
For dual fuel engine, select off/on/start switch to •
“
” off position.
6. Turn emergency main power disconnect switch
to off position.
