Skyjack 8243 User Manual

Mid Size & Full Size RT’s
Engine Powered February 2008
SKYJACK, Page 67
Tables Section 2 - Operation
General Maintenance
Before attempting any repair work, disconnect battery by turning emergency main power disconnect
switch to off position. Preventive maintenance is the easiest and least expensive type of maintenance.
Table 2.8 Maintenance and Inspection Schedule
Frequency
Daily
3 months or
150 hours
Yearly
Frequency
Daily
3 months or
150 hours
Yearly
Lifting Mechanism
Labels A Scissor Guards A
Electrical A Sliders A
Limit Switches A Maintenance Support A
Hydraulic A Scissor Assembly A
Hydraulic/Electrical Compartment Scissor Bumpers A
Emergency Main Power Disconnect Switch A Lift Cylinder(s) A
Base Control Switches A Base
Battery A Base Weldment A
Manifolds A Wheel/Tire Assembly A
Electrical Panel A Drive Axle A
Tilt Sensor A Steer Cylinder Assembly A
Hydraulic Tank (Model 9250) A Tie Rod A
Hydraulic Oil (Model 9250) A Disc Brake (Models 71xx & 8xxx) A
Emergency Lowering Access Rod (If Equipped) A Pin Brakes (Model 9250) A
Hydraulic/Fuel Compartment Drive Motor A
Hydraulic Tank (Models 71xx & 8xxx) A Ladder A
Hydraulic Oil (Models 71xx & 8xxx) A Outriggers A
Fuel Tank A Manuals A
Fuel Leaks A Function Tests
Engine Compartment Test Emergency Main Power Disconnect Switch A
Engine Control Console A Base Control Console
Radiator A Test Platform Raise/Lower Switch A
Muffler and Exhaust A Test Emergency Lowering (Models 71xx & 8xxx) A
Engine Tray A Test Emergency Lowering (Model 9250) A
Hydraulic Pump A Platform Control Console
Engine Oil Level A Test Emergency Stop A
Engine Air Filter A Test Enable Trigger Switch A
Fuel Leaks A Test Platform Raising/Lowering A
Platform Assembly Test Steering A
Lanyard Attachment Anchors A Test Driving A
AC Outlet on Platform A Test Speed Limit A
Platform Control Console A Test Brakes A
Powered Extension Control Console (If Equipped) A Test Horn A
Test Tilt Sensor A
60603AA-ANSI
A - Perform Visual and Daily Maintenance Inspections & Functions Test. Refer to Section 2.8 and Section 2.9 of this manual.
B - Perform Scheduled Maintenance Inspection. Refer to Service & Maintenance manual.
* - Maintenance must be performed only by trained and competent personnel who are familiar with mechanical procedures.
B*
Visual and Daily Maintenance Inspections
B*
B*
WARNING
Use original or manufacturer-approved parts and components for aerial platform.
