Skyjack 8243 - Table 2.6 Floor Loading Pressure

SKYJACK, Page 64
February 2008
Mid Size & Full Size RT’s
Engine Powered
Section 2 - Operation Tables
Table 2.6 Floor Loading Pressure
lb. kg lb. kg psi kPa psf
kg/m
2
min*
7920 3592 3168 1437 101.7 701.2 150.0 732.4
max*
12180 5525 4872 2210 121.1 835.0 230.7 1126.4
7127
min*
9360 4246 3744 1698 47.7 328.8 155.5 759.2
Outrigger Pads
max*
12180 5525 4872 2210 62.1 427.9 202.3 987.9
min*
8850 4014 3540 1606 106.8 736.4 167.6 818.4
max*
11980 5434 4792 2174 120.4 830.1 226.9 1107.9
7135
min*
9790 4441 3916 1776 49.9 343.9 162.6 794.1
Outrigger Pads
max*
12110 5493 4844 2197 61.7 425.5 201.2 982.2
min*
10600 4808 4240 1923 115.0 792.9 169.9 829.5
max*
11980 5434 4792 2174 120.4 830.1 192.0 937.4
8243
min*
10600 4808 4240 1923 54.0 372.4 176.1 859.8
Outrigger Pads
max*
12920 5860 5168 2344 65.8 453.9 214.6 1047.9
min*
11460 5198 4584 2079 118.4 816.3 167.8 819.3
max*
12530 5684 5012 2273 122.3 843.2 183.5 895.8
8850
min*
11460 5198 4584 2079 58.4 402.6 196.2 958.2
Outrigger Pads
max*
12530 5684 5012 2273 63.8 440.2 214.6 1047.6
min*
9670 4386 3868 1754 110.9 764.6 148.8 726.4
max*
13350 6055 5340 2422 125.0 861.8 205.4 1002.9
8831
min*
10540 4781 4216 1912 53.7 370.3 157.1 767.0
Outrigger Pads
max*
14300 6486 5720 2594 72.9 502.4 213.1 1040.6
min*
10570 4794 4228 1918 114.9 792.2 162.6 794.0
max*
13830 6273 5532 2509 126.4 871.5 212.8 1038.9
8841
min*
11440 5189 4576 2076 58.3 401.9 170.5 832.5
Outrigger Pads
max*
14820 6722 5928 2689 75.5 520.7 220.9 1078.4
min*
14700 6668 5880 2667 128.9 888.7 179.5 876.4
max*
17470 7924 6988 3170 135.6 934.9 213.3 1041.5
9250
min*
14700 6668 5880 2667 74.9 516.4 145.5 710.7
Outrigger Pads
max*
18410 8351 7364 3340 93.8 646.8 182.3 890.0
60379AD-ANSI
*
**
NOTE:
The LCP or OUP that an individual surface can withstand varies from structure to structure and is generally determined
by the engineer or architect for that particular structure.
min - Total aerial platform weight with no options
max - Aerial platform weight + all options
LCP - Locally Concentrated Pressure
is a measure of how hard the aerial platform presses on the areas in direct
contact with the floor. The floor covering (tile, carpet, etc.) must be able to withstand more that the indicated values
above.
OUP - Overall Uniform Pressure is a measure of the average load the aerial platform imparts on the whole surface
directly underneath it. The structure of the operating surface (beams, etc.) must be able to withstand more than the
indicated values above.
7135
8831
8841
9250
8243
8850
MODEL
Total Aerial Platform Load
7127
WHEEL LCP ** OUP **
Total Aerial Platform
Weight
