60
Section 6 – Additional Procedures Move the MEWP for transport
Figure 04 Appropriate method to hoist
Forklift Lifting
Locations
Center of
Gravity
Figure 05 Center of gravity and forklift lift locations
NOTE
For the weight of the MEWP, refer to
Section 7.3. The center of gravity is approximately in
the middle of the MEWP, front to back and side to side.
Refer to Figure 05. Vertically, the center of gravity is
approximately a small distance above the base..
NOTE
A forklift truck can lift the MEWP from the back. Lift with
the forks in the forklift lift locations as shown in Figure
05.
25% 25%
Gradeability 25%: Climbing reverse, descending
forward
Gradeability 25%: Climbing forward, descending
reverse
Figure 06 Maximum gradeability of inclined drive
CAUTION
Make sure you use the correct lift method. An
incorrect lift method, such as the one in Figure 04,
can cause damage to the MEWP.
