Labels Section 8 – Labels
Description Label Pictorial
5
Platform extension lock-pin
Shows the location of the platform extension pin, which is on the
inner face at the front of the left and right guardrails.
TM
6
Platform capacity*
Shows the rated work load in each configuration.
*Each model has different platform capacities.
Horizontal load rating**
Do not apply more than the specified side load. Operate the
MEWP when the wind speed, which includes wind gusts, is less
than the specified speed for this model.
**The rating changes between different units.
0 m/s (0 mph)
TM
N
kg kg kg
( lb)
( lb) ( lb) ( lb)
0 m/s
(0 mph
>
7
AC power plug
Connect the AC supply here.
TM
8
Platform control cable
Insert the platform control console cable in the bracket and lock
it with the lock-pin.
TM
Platform continued
8
6
7
5
