SJ3215, SJ3219, SJ3220, SJ3226, SJ4726, SJ4732, SJ4740 216380ACA
27
General components Section 3 – Familiarization
FAMILIARIZATION
3.4-10 Maintenance support(s)
Use the maintenance support(s)
1
when you do an
inspection of the lift mechanism or do maintenance.
Refer to Section 6.8 for the procedure on how to use
the maintenance support(s).
NOTE
SJ4740 model has two maintenance supports. All
other models only have one maintenance support.
1
1
3.5 General components
3.5-1 AC power socket on the platform
The AC power socket is a source of AC power on the
platform when the plug at the base is connected to a
generator or an external power supply.
WARNING
Do not use AC power on the platform when in
hazardous areas.
3.5-2 Battery charger
The charger is located at the base. Refer to Section
6.7 for the battery charger operation.
