Skyjack SJ4740 - Page 76

216380ACA SJ3215, SJ3219, SJ3220, SJ3226, SJ4726, SJ4732, SJ4740
76
Section 6 – Procedures
Fold the guardrails
WARNING
Fall hazard. Use the three points of contact
principle when you use the MEWP ladder to enter
or exit the platform. If you do not obey, there is a
risk of death or serious injury.
11. Use the MEWP ladder to enter the platform.
12. Close the gate.
13. Install the lock-pins on the top rear guardrail.
14. Remove the lower lock-pins from the extension
handrails.
15. Push the extension handrails, and install all the
lock-pins. Refer to Figure 23.
16. Install the platform control console onto the
mounting bracket. Install the lock-pin
1
in the
mounting bracket.
17. Put the cable of the platform control console
into the railing clamp. Install the lock-pin
2
on
the railing clamp.
2
1
18. For SJ3226 only:
a. Put the dual height control console on the
top bracket.
b. Tighten the wing screw from the top bracket
of the dual height control console.
WARNING
Before you operate this MEWP, make sure that
the guardrail system does not have loose or
missing lock-pins. The guardrail system must be
in the vertical position. Lock all pins correctly. An
incorrectly locked guardrail can cause a fall, which
can result in death or serious injury.
